OM4 10Gbps LSZH Jacket LC-LC Simplex Multimode Fiber Patch Cable
The OM4 10Gbps LSZH Jacket LC-LC Simplex Multimode Fiber Patch Cable is engineered for high-speed data transmission in modern network infrastructures. Designed for 10Gbps performance, it provides low signal loss, high reliability, and optimal bandwidth over medium-distance connections. The LC-LC simplex connectors ensure precise alignment and secure connections, making this patch cable ideal for data centers, telecom networks, and enterprise LAN environments.
The Low Smoke Zero Halogen (LSZH) jacket enhances safety by reducing toxic fume emissions in case of fire, making it suitable for indoor installations and high-density networking setups.
Share:
Detailed Features and Product Specifications
- High-Speed Transmission: Supports up to 10Gbps network speeds for high-performance data applications.
- Multimode OM4 Fiber: Optimized for 850nm wavelength, offering 150 meters of reliable transmission for typical 10GbE applications.
- LSZH Jacket: Ensures low smoke emission and halogen-free properties, ideal for commercial and industrial indoor use.
- Simplex LC-LC Connectors: Pre-terminated with LC connectors on both ends, providing easy plug-and-play installation and reduced insertion loss.
- Durable and Flexible Design: Robust fiber core and outer jacket resist bending, kinking, and physical stress, ensuring long-term performance.
- Low Insertion Loss and Return Loss: Maintains signal integrity and reduces network interference, critical for high-speed and high-density environments.
- Industry Standard Compliance: Conforms to TIA/EIA-492AAAD, ISO/IEC 11801, and RoHS standards, ensuring quality and safety compliance.
Applications
- Data Centers: High-speed backbone connections for servers, switches, and storage systems.
- Telecommunication Networks: Supports optical networking, LAN, and MAN infrastructure.
- Enterprise Networks: Optimizes office LANs, meeting rooms, and structured cabling systems.
- FTTx Deployments: Suitable for fiber-to-the-building or fiber-to-the-premises applications.
- High-Density Racks: Compatible with patch panels and optical distribution frames.
Comparison with Similar Fiber Patch Cables
| Feature / Product | OM4 LC-LC Simplex | OM3 LC-LC Simplex | OM4 SC-SC Duplex | Single Mode LC-LC |
|---|---|---|---|---|
| Bandwidth | 4700 MHz·km | 2000 MHz·km | 4700 MHz·km | N/A |
| Max Data Rate | 10Gbps | 10Gbps | 10Gbps | 1-100Gbps |
| Connector Type | LC-LC | LC-LC | SC-SC | LC-LC |
| Jacket Type | LSZH | PVC | LSZH | LSZH |
| Typical Use | Data centers, LAN | Enterprise LAN | Telecom, LAN | Long-distance telecom |
| Transmission Distance | 150m (10GbE) | 100m (10GbE) | 150m (10GbE) | 10km+ |
Why Choose OM4 LSZH LC-LC Simplex Patch Cable
- Enhanced Performance: Delivers superior bandwidth and transmission distance compared to OM3 cables.
- Safety and Compliance: LSZH jacket ensures safety in indoor environments.
- Ease of Installation: LC-LC connectors allow fast deployment and reduce downtime.
- Durability: Designed for long-term use in high-density networking scenarios.
Question? Check out our answer.
-
Q1: What is the maximum data rate supported by this OM4 fiber patch cable?
A: The OM4 LC-LC Simplex Fiber Patch Cable supports up to 10Gbps for high-performance network applications.
-
Q2: What type of connectors does this cable use?
A: This fiber patch cable uses LC-LC simplex connectors, suitable for precise plug-and-play connections.
-
Q3: Is the jacket material safe for indoor use?
A: Yes, the LSZH jacket ensures low smoke and halogen-free properties, making it safe for indoor installations.
-
Q4: How long can this cable transmit 10Gbps signals?
A: OM4 multimode fiber supports 10Gbps transmission up to 150 meters over standard LAN applications.
-
Q5: Can this cable be used in high-density patch panels?
A: Yes, the compact LC-LC connectors are designed for high-density racks and patch panels.
-
Q6: Is this cable compatible with OM3 fiber systems?
A: Yes, OM4 cables are backward compatible with OM3 systems, but OM4 provides higher bandwidth and longer reach.
-
Q7: What wavelength does OM4 fiber operate at?
A: OM4 fiber is optimized for 850nm wavelength for maximum 10GbE performance.
-
Q8: Can I use this cable for telecom applications?
A: Yes, it is suitable for enterprise telecom networks and structured cabling systems.
-
Q9: How durable is the cable under physical stress?
A: The cable is designed with a robust fiber core and LSZH jacket to resist bending, kinking, and physical wear.
-
Q10: Does this cable comply with industry standards?
A: Yes, it meets TIA/EIA-492AAAD, ISO/IEC 11801, and RoHS standards for quality and safety.
-
Q11: What is the ideal use case for this cable?
A: It is ideal for high-speed data centers, LAN networks, telecom installations, and FTTx deployments.
-
Q12: Can I use this cable for long-distance outdoor applications?
A: No, this is an indoor LSZH multimode fiber cable designed for medium-distance connections; outdoor or long-distance applications require single-mode fiber.
